Product details
ASTM A335 P5/ P5B / P5C ALLOY STEEL PIPE
Gnee Steel Group is one of the leading specialists in suppling and exporting various types of alloy steel p5, p5b, p5c pipe. We are manufactured in accordance with ASTM A335 / ASME SA335 standards for ferritic alloy synthetic steel pipes and are mainly used for high temperature service. Alloy Steel A335 P5 Seamless Pipe offered by us are available in ASME SA335 as well as P5, P5B, P5C grades. Our experience is based on offering these in different sizes and calendars, with IBR and the latest edition NACE MR 0175 reports. In the meantime, we have achieved the integrity of production technique and systematics in the modern steel industry.These P5 alloy steel pipes are more durable and have a sturdy construction. Engineers and the world's top project consultants use these P5 alloy steel pipes in machined components, valves, machine tools, pump shafts, line pipe, oil and gas industry, dairy equipment, and surgical and medical parts. We also supply and maintain large stocks of ASTM A 335 GR P5, P5B, P5C Seamless tubes of high quality raw materials. These propelled quality products are very solid and are welded using the best methods for greater support capacity.
We store an extensive inventory of high quality ASME SA335 steel alloy P5 pipe, A335 P5 high pressure pipe, alloy steel P5 seamless pipes stockist, Alloy Steel P5 Pipes, ASTM A335 Alloy Steel P5 Seamless Pipe, global supplier of alloy steel P5 pipe, grade P5 ASTM A335 alloy steel pipe, steel alloy P5b chrome Moly pipes distributor. We also offer a competitive range of gr steel alloy. P5 tubes, Grade P5 Alloy Steel Pipe, ASTM A335 High Pressure Steel Alloy P5b Steel Pipe, Alloy Steel A335 Gr. P5 Seamless Pipe, ASTM A335 Seamless Alloy Steel Seamless Pipes, Alloy Steel P5 Seamless Pipe, Alloy Steel Uns K41545, K51545, K41245 Pipes, Alloy Steel P5 Seamless Pipe, Gring Steel Shareholder. P5b seamless tubes, steel alloy grade P5c export pipe.
List of countries where Alloy Tubes supplies ASTM A335 Seamless Steel Alloy P5 / P5B / P5C :
List of countries where Tubes Alloy supplies ASTM A335 Seamless Tube Steel Alloy P5 / P5B / P5C : USA, Mexico, South Korea, Spain, Argentina, Colombia, Malaysia, Saudi Arabia, Turkey, United Kingdom.
Steel seamless steel pipe P5 / P5B / P5c steel alloy
AsTM A335 P5, P5b, p5c seamless steel pipe is the main structural pipe material in the use of construction and high pressure. It will be manufactured by hot rolling and cold stretching. The material used correctly in the transfer of oil and gas, hot water at high pressure, special structure, transport of special chemicals, etc. The outer surface can be treated by galvanizing, painting, PE coating, PP coating, HDPE coating, etc. . The main advantage is that the thickness can be large, then high pressure will be loaded into low quality steel. The normal valid usage time will be around 50-70 years. The standard can be API, ASTM, JIS, etc.
ASTM A335 P5 / P5B / P5C Alloy Steel Seamless Tubes Specifications
Specifications: ASTM A / ASME SA335
Pipe size : 1 / 8NB A 26NB EN
Outside diameter : 6-2500mm; WT: 1-200 mm
Thickness: 0.3 mm - 50 mm
Scheme: SCH20, SCH30, SCH40, STD, SCH80, XS, SCH60, SCH80, SCH120, SCH140, SCH160, XXS
Types : Seamless / EFW / Fabricated
Length: Single random, double random and required length
End: Flat end, beveled end, Treaded
Hot tags :
P5 seamless steel alloy tube, ASTM A335 steel alloy P5 tube, Steel alloy P5B tube, ASTM A335 P5C tube, A335 P5 steel alloy seamless tube.
Alloy steel grade P5/P5B/P5C seamless tubes grade and chemical composition
| Compositions | data | data | data |
| UNS designation | K41545 | K51545 | K41245 |
| charcoal | 0.15 | 0.15 | 0.12 |
| manganese | 0.30-0.60 | 0.30-0.60 | 0.30-0.60 |
| Phosphorus (max.) | 0.025 | 0.025 | 0.025 |
| Sulfur (max.) | 0.025 | 0.025 | 0.025 |
| silicon | 0.5 | 1.00-2.00 | 0.5 |
| nickel | ... | ... | ... |
| chromium | 4.00-6.00 | 4.00-6.00 | 4.00-6.00 |
| molybdenum | 0.44-0.65 | 0.44-0.65 | 0.44-0.65 |
| Other elements | ... | ... | ... |
Alloy steel gr. P5 / P5B / P5C pipes mechanical properties
| Tensile strength, MPa | Performance, MPa | Elongation, % |
| 415 min | 205 min | 30 min |
Outer diameter and tolerance
| ASTM A450 | Hot rolled | Outer diameter, mm | Tolerance, mm |
| OD≤101.6 | +0.4/-0.8 | ||
| 101.6<> | +0.4/-1.2 | ||
| 190.5<> | +0.4/-1.6 | ||
| Cold drained | Outer diameter, mm | Tolerance, mm | |
| OD<> | ±0.10 | ||
| 25.4≤OD≤38.1 | ±0.15 | ||
| 38.1<><> | ±0.20 | ||
| 50.8≤OD<> | ±0.25 | ||
| 63.5≤OD<> | ±0.30 | ||
| 76.2≤OD≤101.6 | ±0.38 | ||
| 101.6<> | +0.38/-0.64 | ||
| 190.5<> | +0.38/-1.14 | ||
| ASTM A530 & ASTM A335 | NPS | Outer diameter, mm | Tolerance, mm |
| 1/8≤OD≤1-1/2 | ±0.40 | ||
| 1-1/2<> | ±0.79 | ||
| 4<> | +1.59/-0.79 | ||
| 8<> | +2.38/-0.79 | ||
| OD>12 | ±1% |
ASTM A335 P5, P5B, P5C Alloy Steel Tube Standard Packaging :
We can give peeled packaging, in packing package, packaging box, wood protection on both sides of pipes and conveniently protected for a dignified maritime delivery. According to customer requirements.
Inspection and testing of seamless steel alloy pipes A335 P5, P5B, P5C :
(Tensile strength, production resistance, elongation, combustion, flattening, bending, hardness, impact test), chemical composition inspection, non-destructive testing, hydrostatic testing.
