Product details
We are manufacturer, warehouseman and exporter of 304 Buttweld stainless steel accessories. We are specialists in proactive organization in 304l stainless steel pipe fittings and other quality products that meet and exceed specific customer requirements and thus ensure total satisfaction. We are your experts in 304h stainless steel butt welding accessories. We have an extensive inventory of elbows, caps, tees, gearboxes, crosses, stainless steel tips and many other stainless steel butt welding accessories to meet your specifications and standards. We are supplying 304 stainless steel butt welding accessories in various shapes, sizes, grades and specification with ANSI/ASME and DIN standards. We are the most preferred manufacturer in Spain to manufacture steel elbows for critical applications, we manufacture and store even odd sizes and accessories difficult to find in steel elbow.
Now we can provide 304 ss butt welding accessories in a single package, and with our distribution expertise, we can ship 304l stainless steel fittings, 304 steel pipe fittings, ASTM A403 pipe fittings worldwide in fast delivery times. Butt welding is a welding technique used to connect parts that are almost parallel and do not overlap. Butt welding is a welding technique used to connect parts that are almost parallel and do not overlap. we are offering a wide range of 304h stainless steel butt welding accessories. SS 304 butt welding fittings include manufactured fittings for pipes that require something out of the ordinary.
List of countries where Gnee Steel Group supplies 304 / 304L / 304H stainless steel pipe fittings :USA, Mexico, South Korea, Spain, Argentina, Colombia, Malaysia, Saudi Arabia, Turkey, United Kingdom.
304 / 304L / 304H Buttweld stainless steel pipe fittings
These 304 stainless steel pipe fittings widely used in various industry applications such as oil and chemical industry, medicine, food, wastewater treatment, boiler pipe and heat exchanger. It is produced by hot and cold laminate. The glossy surface is the biggest advantage and is mainly used in buildings, elevators, railings, precision equipment, etc.
Specifications for 304 / 304L / 304H stainless steel pipe fittings
Standards: ASTM A403 / ASME SA403
Standard dimension : ASME / ANSI B16.9, ASME B16.28, MSS-SP-43
Size : 1/2" to 24"
Two sizes of Joint / Two Halve 304 / 304L / 304H pipe fittings : 6" to 48"
Thickness: Sch 5s, Sch 10s, Sch 40s, Sch 80s, Sch 160s, Sch XXS
Types : Seamless / Welded / Manufactured
Types of butt welding accessories : Elbows, Long Radius Elbow, Short Radius Elbow, 90 Degree Elbow, 45o Elbows, Reduction T-Shirt, Equal T, Niple, Reducer, Concentric Reducer, Reduction Niple, Eccentric Reducer, Curve, 180o Elbow, End Cap, Tube, Tube Cap, Piggable Curve, Long Stubend, Tee, Shortend, Long Radius Bend.
Hot tags :
Stainless steel pipe fittings, 304 steel pipe fittings, seamless 304L stainless steel pipe fittings, welded 304H stainless steel pipe fittings, ASTM A403 stainless steel pipe elbow.
304 / 304L / 304H Steel Pipe Accessories Chemical composition
| steel | C (%) | Mn (%) | Yes (%) | P (%) | S (%) | Faith (%) | Cr (%) | Ni (%) |
| 304 | .08 max | 2 max | 1 max | .045 max | .03 min | balance | 18 - 20 | 8 - 10.5 |
| 304L | .035 max | 2 max | 1 max | .045 max | .03 min | balance | 18 - 20 | 8 - 13 |
| 304H | .10 max | 2 max | .75 max | .045 max | .03 min | balance | 18 - 20 | 8 - 10.5 |
Stainless steel WP304 / 304L / 304H pipe fittings mechanical properties
| density | Melting range, C | Elongation% | Tensile strength (Mpa) | Production Force (Mpa) | Hardness (Brinell) |
| 8 | 1400oC | 40 | 515 | 205 | 201 |
Equivalent standard for 304 / 304L / 304H stainless steel pipe fittings
| standard | SS 304 | SS 304L | SS 304H |
| Uns | S30400 | S30403 | S30409 |
| WERKSTOFF NR. | 1.4301 | 1.4306 / 1.4307 | 1.4301 |
| Afnor | Z7CN18-09 | Z3CN18-10 | - |
| Jis | YOUR 304 | YOUR 304L | - |
| GOST | 08Х18Н10 | 03Х18Н11 | - |
| Bs | 304S31 | 304S11 | - |
| in | X5CrNi18-10 | X2CrNi18-9 / X2CrNi19-11 | - |
ASTM A403 Stainless Steel 304 / 304L /304H Standard Packaging Pipe Fittings :
Stainless Steel 304 Butt Welding Accessories Are packed to ensure no damage during transit. In the case of exports of 304L stainless steel accessories, standard export packaging is carried out in wooden boxes. All 304H stainless steel pipe fittings are marked with grade, lot not, size, grade and our trademark. In special requests we can also make custom marks on our products.
Inspection and testing of 304 / 304L / 304H butt welding accessories :
PMI tests, ultrasonic tests, mechanical tests, spectral tests for chemical grade analysis, burning test, IGC, etc. are some of the tests performed in our facilities. We welcome the gradual inspection of any of your representatives or third party inspection agencies.
